C Type Cylindrical Tungsten Steel Grinding Head

Ask Lasest Price
Brand Name :	KTS
Model Number :	C
Certification :	ISO9001:2008
Price :	USD1-10 Piece
Payment Terms :	T/T
Supply Ability :	250000 Piece/Pieces per Month
Delivery Time :	7-30days

Add to Cart

Product Details
Company Profile

C Type Cylindrical Tungsten Steel Grinding Head

C Type Cylindrical Tungsten Steel Grinding Head

Double slot:
High-performance tungsten carbide rotary file with cross teeth. Compared with single tooth, cross tooth has higher cutting ability. This is especially beneficial for materials that are difficult to cut. Application field: Used in high alloy steel, stainless steel, acid-resistant steel, heat-resistant steel, die-casting parts and plastics. Deburring, edge breaking, trimming, welding seam processing, surface treatment.

Feature:
1.Tungsten carbide grinding heads can be used to process metals such as cast iron, cast steel, carbon steel, alloy steel, stainless steel, copper, aluminum, and non-metals such as marble, jade, and bones. The processing hardness is as high as HRC58-60.
2.The leaf handle wheel can be replaced, no dust pollution, processing various high-precision mold cavities. The production efficiency is high, and the processing efficiency is several times higher than that of a file, and nearly ten times higher than that of a small wheel handle.
3.Suitable for woodworkers and hobbyists who often clean welds or metal processing. Easy to master and use. The unique tooth angle prevents chipping.
4.Mainly used for grinding channel impellers, cleaning pipes, finishing and reaming the inner surface of machinery, metal and non-metal processing and engraving.

Technical date

S.N.	MATERIAL
1a	Steel
1b	Hard steels
2	Stainless steel
3	Cast iron
4	Titanium
5	Nickel
6	Copper/Copper alloys
7	Aluminum
8	Plastics
9	Cement

Guide to running speeds

mat nr. MAX RPM	3mm/0.123" 90,000	6mm/0.250" 50,000	10mm/0.375" 40,000	12mm/0.500" 35,000	16mm/0.625' 25,000
1a	60,000-80,000	35,000-45,000	22,500-35,000	20,000-30,000	15,000-20,000
1b	60,000-80,000	30,000-45,000	19,000-30,000	15,000-22,500	12,000-18,000
2	60,000-80,000	30,000-45,000	19,000-30,000	15,000-22,500	12,000-18,000
3	45,000-80,000	22,500-45,000	15,000-35,000	11,000-30,000	9,000-20,000
4	60,000-80,000	30,000-45,000	19,000-30,000	15,000-22,500	12,000-18,000
5	60,000-80,000	30,000-45,000	19,000-30,000	15,000-22,500	12,000-18,000
6	45,000-80,000	22,500-45,000	15,000-35,000	11,000-30,000	3,000-20,000
7	30,000-80,000	15,000-45,000	10,000-35,000	7,000-30,000	6,000-20,000
8	30,000-80,000	15,000-45,000	10,000-35,000	7,000-30,000	6,000-20,000
9	60,000-80,000	30,000-45,000	19,000-30,000	15,000-22,500	12,000-18,000
