Certified Carbide Burr Double Cut Cutting Tools Alloy Rotary File
Carbide Rotary Burrs, often referred to as rotary files or die
grinder bits are used for cutting, shaping, and grinding, and for
the removal of sharp edges, burrs and excess material (deburring).For drilling holes in hard metals you would need to use carbide
micro drills or carbide straight shank drills. For cutting slots,
routing, profiling, contouring, counter-boring, and reaming you
would use a a carbide end mill, carbide slot drill or a carbide
router. For cutting and shaping stone or glass you would use a
Diamond Burr.
Technology
• In-house designed, fully automated equipment for cost-effective
manufacture.
Innovation
• Continuous investment in customer and application driven
development of new products, giving you effective solutions.
Support
• Technical, sales and customer service teams backed up with large
product stocks all provide exceptional ser
People
• Stainless steel (INOX)Professional, friendly staff throughout the worldcreate the
relationships you need.
Technical Date
| S.N. | Materials |
| 1a | Steel |
| 1b | Hard steels |
| 2 | Stainless steel |
| 3 | Cast iron |
| 4 | Titanium |
| 5 | Nickel |
| 6 | Copper/Copper alloys |
| 7 | Aluminum |
| 8 | Plastics |
| 9 | Cement |
Guide to riunning speeds
mat nr. MAX RPM | 3mm/0.125" 90,000 | 6mm/0.250" 50,000 | 10mm/0.375" 40,000 | 12mm/0.500" 35,000 | 16mm/0.625" 25,000 |
| 1a | 60,000-80,000 | 35,000-45,000 | 22,500-35,000 | 20,500-30,000 | 15.000-20,000 |
| 1b | 60,000-80,000 | 30,000-45,000 | 19,000-30,000 | 15,000-22,500 | 12,000-18,000 |
| 2 | 60,000-80,000 | 30,000-45,000 | 19,000-30,000 | 15,000-22,500 | 12,000-18,000 |
| 3 | 45,000-80,000 | 22,500-45,000 | 15,000-35,000 | 11,000-30,000 | 9,000-20,000 |
| 4 | 60,000-80,000 | 30,000-45,000 | 19,000-30,000 | 15,000-22,500 | 12,000-18,000 |
| 5 | 60,000-80,000 | 30,000-45,000 | 19,000-30,000 | 15,000-22,500 | 12,000-18,000 |
| 6 | 45,000-80,000 | 22,500-45,000 | 15,000-35,000 | 11,000-30,000 | 9,000-20,000 |
| 7 | 30,000-80,000 | 15,000-45,000 | 10,000-35,000 | 7,000-30,000 | 6,000-20,000 |
| 8 | 30,000-80,000 | 15,000-45,000 | 10,000-35,000 | 7,000-30,000 | 6,000-20,000 |
| 9 | 60,000-80,000 | 30,000-45,000 | 19,000-30,000 | 15,000-22,500 | 12,000-18,000 |
Carbide Burrs Can be Used on Many Materials
Die grinder bits can be used on a multitude of materials: metals including steel,
aluminum and cast iron, all types of wood, acrylics, fibreglass and
plastics. Carbide burrs are also perfect for working on softer
metals such as gold, platinum and silver as they last a long time
with no chipping or breaking.
- Steel, Carbon Steel & Stainless Steel
- Cast Iron
- Aluminium
- Titanium
- Cobalt
- Nickel
- Gold, Platinum & Silver
- Ceramics
- Fibreglass
- Plastic, Carbon Fiber Reinforced Plastic (CRP), Glass Fibre
Reinforced Plastic (GRP)
- Brass, Copper & Bronze
- Zinc
- Wood
Advantages
- Long life
- Use for long production runs
- High stock removal
- Ideal for using on many hard and tough materials
- Ideal for Deburring, finishing, carving, shaping and smoothing
welds, moulds, dies and forgings
Company Introduction
Zigong Jincheng Cemented Carbide Tools Co., Ltd. is one of the
market leaders in China that produces and sells rotary burrs,
teeth, bars, blanks, alloy plates, nozzles and more. We were
established in China in 2007. As a tool company from raw material
to finished product processing and research, we can provide
semi-finished products, finished products, customized services and
other services. Our products have been exported to more than 30
countries and regions in the United States, Britain, Germany,
France, Mexico, Canada, Russia, Japan, Australia, and the Middle
East. Chengdu Jinyuan New Material Co., Ltd. is a subsidiary of
Zigong Jincheng Cemented Carbide Tools Co., Ltd., which is
committed to providing customers with quality services, products
and preferential prices.
Stay Safe
- Always ensure your burr shank is well inserted into your collet and
clamped down tightly
- Keep pressure light and keep the bur moving, focusing on the
highest material first
- Ensure your work is secured tightly to your work bench
- Don't snag or jam your burr into your work
- Wear eye protection as a minimum, but better still use a full
shield for your face
