Black Solid Carbide Materials 6mm End Mill Cutter , Durable Long Shank End Mills

Ask Lasest Price
Brand Name :	KTS
Model Number :	LQ4
Certification :	ISO9001：2008
Price :	1USD-20USD
Payment Terms :	T/T, Western Union
Supply Ability :	10000 PIECES/Month
Delivery Time :	7-30 Days

Add to Cart

Product Details
Company Profile

Black Solid Carbide Materials 6mm End Mill Cutter , Durable Long Shank End Mills

Black Solid Carbide Materials 6mm End Mill Cutter , Durable Long Shank End Mills

Type:

1. Cylinder milling cutter

Used for processing planes on horizontal milling machines. The cutter teeth are distributed on the circumference of the milling cutter, and are divided into straight teeth and spiral teeth according to the tooth shape. There are two kinds of coarse teeth and fine teeth according to the number of teeth. The spiral tooth coarse tooth milling cutter has few teeth, high tooth strength, and large chip space, suitable for rough machining; fine tooth milling cutter is suitable for finishing.

2. Face milling cutter

It is used for machining planes on vertical milling machines, end milling machines or gantry milling machines. There are cutter teeth on the end face and the circumference, and there are also coarse and fine teeth. Its structure has three types: integral type, insert type and indexable type.

3. End mill

It is used for processing grooves and stepped surfaces. The cutter teeth are on the circumference and the end surface, and they cannot be fed in the axial direction during work. When there is an end tooth passing through the center on the end mill, it can be fed axially.

4. Three-sided cutter

It is used to process all kinds of grooves and step surfaces, and has teeth on both sides and circumference.

5. Angle cutter

There are two types of single-angle and double-angle milling cutters for milling grooves at a certain angle.

6. Saw blade milling cutter

For machining deep grooves and cutting off workpieces, there are many cutter teeth on the circumference. In order to reduce the friction during milling, there are 15 '~ 1 ° side angles on both sides of the cutter teeth. In addition, there are keyway milling cutters, dovetail milling cutters, T-slot milling cutters and various forming milling cutters.

7. T-shaped milling cutter

Used for milling T-slots.

Technical date

S.N.	MATERIAL
1a	Steel
1b	Hard steels
2	Stainless steel
3	Cast iron
4	Titanium
5	Nickel
6	Copper/Copper alloys
7	Aluminum
8	Plastics
9	Cement

Guide to running speeds

mat nr. MAX RPM	3mm/0.123" 90,000	6mm/0.250" 50,000	10mm/0.375" 40,000	12mm/0.500" 35,000	16mm/0.625' 25,000
1a	60,000-80,000	35,000-45,000	22,500-35,000	20,000-30,000	15,000-20,000
1b	60,000-80,000	30,000-45,000	19,000-30,000	15,000-22,500	12,000-18,000
2	60,000-80,000	30,000-45,000	19,000-30,000	15,000-22,500	12,000-18,000
3	45,000-80,000	22,500-45,000	15,000-35,000	11,000-30,000	9,000-20,000
4	60,000-80,000	30,000-45,000	19,000-30,000	15,000-22,500	12,000-18,000
5	60,000-80,000	30,000-45,000	19,000-30,000	15,000-22,500	12,000-18,000
6	45,000-80,000	22,500-45,000	15,000-35,000	11,000-30,000	3,000-20,000
7	30,000-80,000	15,000-45,000	10,000-35,000	7,000-30,000	6,000-20,000
8	30,000-80,000	15,000-45,000	10,000-35,000	7,000-30,000	6,000-20,000
9	60,000-80,000	30,000-45,000	19,000-30,000	15,000-22,500	12,000-18,000

We can customize what you want, and provide high quality to you, so choose us!
