Hand Tools Double Cut Tungsten Carbide Rotary Files Carbide Burrs
Set Tungsten Carbide Bur
Product Description
The Rapid Abrasives Cylindrical Double Cut Carbide Burr is built to
grind flat surfaces on metal and non-ferrous metal applications.
Build Excellent for light to medium material removal.
This solid carbide burr is double cut with a chisel tooth cutting
pattern that produces small chips instead of long, sharp slivers
which help to finish the metal surfaces faster, eliminates loading
and minimizes chatter to provide a smooth cutting experience.
Operation
Moving the burr over the surface gradually will help remove only
the material wanted and will help prevent the burr from making
divots and unsightly marks.
To extend the life of the burr, only apply enough pressure to let
the burr do the work. This eliminates unnecessary wear to the burr.
Technical date
| S.N. | MATERIAL |
| 1a | Steel |
| 1b | Hard steels |
| 2 | Stainless steel |
| 3 | Cast iron |
| 4 | Titanium |
| 5 | Nickel |
| 6 | Copper/Copper alloys |
| 7 | Aluminum |
| 8 | Plastics |
| 9 | Cement |
Guide to running speeds
mat nr. MAX RPM | 3mm/0.123" 90,000 | 6mm/0.250" 50,000 | 10mm/0.375" 40,000 | 12mm/0.500" 35,000 | 16mm/0.625' 25,000 |
| 1a | 60,000-80,000 | 35,000-45,000 | 22,500-35,000 | 20,000-30,000 | 15,000-20,000 |
| 1b | 60,000-80,000 | 30,000-45,000 | 19,000-30,000 | 15,000-22,500 | 12,000-18,000 |
| 2 | 60,000-80,000 | 30,000-45,000 | 19,000-30,000 | 15,000-22,500 | 12,000-18,000 |
| 3 | 45,000-80,000 | 22,500-45,000 | 15,000-35,000 | 11,000-30,000 | 9,000-20,000 |
| 4 | 60,000-80,000 | 30,000-45,000 | 19,000-30,000 | 15,000-22,500 | 12,000-18,000 |
| 5 | 60,000-80,000 | 30,000-45,000 | 19,000-30,000 | 15,000-22,500 | 12,000-18,000 |
| 6 | 45,000-80,000 | 22,500-45,000 | 15,000-35,000 | 11,000-30,000 | 3,000-20,000 |
| 7 | 30,000-80,000 | 15,000-45,000 | 10,000-35,000 | 7,000-30,000 | 6,000-20,000 |
| 8 | 30,000-80,000 | 15,000-45,000 | 10,000-35,000 | 7,000-30,000 | 6,000-20,000 |
| 9 | 60,000-80,000 | 30,000-45,000 | 19,000-30,000 | 15,000-22,500 | 12,000-18,000 |
Application:
It can be processed cast iron, cast steel, carbon steel, alloy
steel, stainless steel, copper, aluminum and other metals, and
marble, jade, bone and other non-metallic. Processing hardness up
to HRA85.
Advantage:
1. 10 years professional experience.
2. 100% new material.
3. Be more durable.
4. OEM & ODM Service.
5. All payment terms supported.
6. Fast delivery time & Convenient Transportation
Packing
About us
Zigong (Chengdu) Cemented Carbide Co., Ltd. is a subsidiary of
Zigong Cemented Carbide Co., Ltd., which specializes in the
production of cemented carbide rotating tools and cemented carbide
materials. We have two branches, one is located in Chengdu City,
Sichuan Province, and the other is located in Zigong City, Sichuan
Province.
Founded in 2007 in Zigong City, Sichuan Province. In China, we are
an exclusive factory with production equipment from raw materials
to finished tools. Including inclined wet grinding, pressing, low
pressure sintering, five-axis CNC, electronic tool surface scanner,
hardness tester and TRS. The main products include cemented carbide
end mills / cemented carbide end mill blanks / cemented carbide
tool holders and cemented carbide nozzles. We have exported to
North America, Europe, Asia, etc. We helped make world-class cheap
products.
